Round ASTM Square Brushed Polished Welded Stainless Steel Tube Pipe for Applications
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | 300 Series, 310S, 316Ti, 316L, 316, 321, 304, 304L | Surface Treatment | Bright |
|---|---|---|---|
| Delivery Time | 7-10 Working Days | Length | 6m, 10m, 12mm, As Customer′s Request |
| MOQ | 1 Ton | Transport Package | Customized |
| Specification | 201 301 304 316 316L 310S 321 410 420 430, Etc. | Trademark | ZNGL STEEL |
| Origin | Shandong, China | Supply Ability | 50000000ton/Year |
| Type | Stainless Steel Pipes | Standard | ASTM, AISI, GB, JIS, ASTM, AISI, GB, JIS, DIN, En |
| Grade | 300 Series | Certification | ISO, ISO, RoHS, Ibr, AISI, ASTM, GB, En, DIN, JIS |
| Shape | Round | Technique | Hot Rolled |
| Samples | US$ 0/Piece 1 Piece(Min.Order) | Request Sample | Customization | Available | Customized Request |
Product Description
| Name | Stainless steel 316 pipe price list | |||||
| Standard | ASTM A554,ASTM A312 | |||||
| Material Grade | 201,202,304,316,316L,430 | |||||
| Main Material | a) 201 (Ni0.8%-1%) | |||||
| b) 202 (Ni: 3.0%-4.0%) | ||||||
| c) 304 (Ni: 8% Cr: 18%) | ||||||
| d) 316 (Ni: 10% Cr: 18%) | ||||||
| Size Range | 139mm-1600mm ETC. | |||||
| Thickness | 0.5-30mm | |||||
| Length | 6m or as customers' request | |||||
| a) Outer Diameter: +/- 0.2mm | ||||||
| Tolerance | b) Thickness: +/- 0.02mm | |||||
| c) Length: +/- 5mm | ||||||
| Surface | 180G, 320G Satin/Hairline | |||||
| 400G, 600G Mirror finish | ||||||
| Application | handrail,railing, staircase, weldmesh screen,door,window, balcony,fence,bench,furniture,etc | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
| Material | 201 | 202 | 304 | 316L | 430 | |
| Composition | ||||||
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.035 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Chemical Composition | Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 |
| of Material | P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 13-15 | 14-17 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.7-1.1 | 3.5-4.5 | 8-10.5 | |||
| Mo | 2.0-3.0 | |||||
| Material Item | 201 | 202 | 304 | 316 | ||
| Mechanical Property | Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | |
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <105 | <100 | <90 | <90 | ||
